ARISTO 5000
- PENTIUM Multimedia ATX
Motheboard
PENTIUM Multimedia ATX
Motherboard with built-in S3 ViRGE 3D
Acceleration and YAMAHA 3D Surround Audio
chipset. Supports Intel P54C/P55C, Cyrix
6x86 and AMD K5 processors with 256K PB
Cache. Flash Award BIOS for Plug &
Play / DMI Features to provide an
easy-to-use add-on cards configuration.
Integrated 2 Serial (16550) / 1 Parallel
(ECP/EPP) ports, dual Bus Master IDE, FDC
Controller and USB port option.
|
- Multimedia
ATX design based on Intel 430VX chipset.
- Integrated
with on-board ViRGE 3D Graphics and Video
Accelerator chipset with quality
performance for 3D display.
- Built-in
YAMAHA 3D Surround Audio chipset with
Software Wavetable and Full Duplex
Capability.
- Selectable
voltage to support Intel P54C/P55C, Cyrix
6x86 and AMD K5 processors.
- Windows 95
Plug & Play Compliance with Flash
BIOS, FP/EDO/Burst EDO DRAM support.
- Supports
4MB~128MB FP/EDO DRAM utilizing 2x 72 pin
SIMMs sockets or 2x168 pin DIMMs.
- Provides
3x16-bit ISA compatible slots & 3x
32-bit PCI 2.1 expansion slots.
- Integrated 2
Serial (16550) / 1 Parallel (ECP/EPP) / 2
Bus Master EIDE & FDC /2 USB port
option.
- Supports USB
Port pin header for Device Expansion
& optional infrared IR.
All other
trademarks menitional herein are the property of
their respective companies.
Specification subject to change without prior
notice.
|
 |
|
